Tp-Link EAP110 - Outdoor Wifi Antenna 300Mbps Wireless N Outdoor Access Point | EAP110-Outdoor

HARDWARE FEATURES: • Interface : Fast Ethernet (RJ-45) Port *1（Support Passive POE） • Version 3.0 • Button : Reset • Power Supply: 24VDC / 1A Passive POE Supply • Power Consumption: 7.7W • Wireless Standards: IEEE 802.11n, IEEE 802.11g, IEEE 802.11b • Dimensions : ( W x D x H ) 7.1 x 7.1 x 1.9 in. (180*180*47.5mm) • Dimensions: 7.5×6.8×1.2 in. (189.4×172.3×29.5mm) • Antenna Type: Internal 2* 3dBi Omni • Mounting: Ceiling /Wall Mounting (Kits included) • Physical Security Lock: Kensington Lock Slot • Watch Dog: Yes • WIRELESS FEATURES: • Wireless Standards: IEEE 802.11n, IEEE 802.11g, IEEE 802.11b • Frequency: 2.4-2.4835GHz • Signal Rate: 11n: Up to 300Mbps(dynamic) • 11g: Up to 54Mbps(dynamic) • 11b: Up to 11Mbps(dynamic) • Reception Sensitivity 300M: -71dBm@10% PER • 150M: -75dBm@10% PER • 54M: -78dBm@10% PER • 11M: -93dBm@8% PER • 6M: -92dBm@10% PER • 1M: -96dBm@8% PER • Wireless Functions Multiple SSIDs （Up to 8 SSIDs） • Enable/Disable Wireless Radio • Automatic Channel Assignment • Transmit Power Control （Adjust Transmit Power on dBm） • QoS (WMM) • Rate Limit • Reboot Schedule • Wireless Schedule • Wireless Statistics based on SSID/AP/Client • Wireless Security Captive Portal Authentication • Access Control • Wireless Mac Address Filtering • Wireless Isolation Between Clients • SSID to VLAN Mapping • Rogue AP Detection • 802.1X Support • 64/128/152-bit WEP / WPA / WPA2-Enterprise,WPA-PSK / WPA2-PSK • Transmission Power CE: • <20dBm • FCC: • <26dBm • MANAGEMENT • Omada Cloud Access Yes • Omada App Yes • Omada Cloud Controller Yes • Omada Controller Software Yes • EAP Controller Software Yes • Email Alerts Yes • LED ON/OFF Control Yes • Management MAC Access Control Yes • SNMP v1,v2c • System Logging Local/Remote Syslog Local/Remote Syslog • Telnet Yes • SSH Yes • Web-based Management HTTP/HTTPS • Management VLAN Yes • OTHERS • Certification CE, FCC, RoHS • Package Contents 300Mbps Wireless N Ceiling Mount Access Point EAP110 • Passive POE Adapter, • Power Cord, • Mounting Kits, • Resource CD • Installation Guide • System Requirements Microsoft Windows 10/8/7/Vista/XP • Environment Operating Temperature: 0℃~40℃ (32℉~104℉) • Storage Temperature: -40℃~70℃ (-40℉~158℉) • Operating Humidity: 10%~90% non-condensing • Storage Humidity: 5%~90% non-condensing • SKU: PH2019132
